Working with System Alarms
AnaWin User’s Guide 11-3
TABLE 11-1 Alarm Types
Alarm Symbol
The Alarm column displays the symbol for the alarm. Table 11-2
defines the alarm symbols.
TABLE 11-2 Alarm Symbols
Clear View
Click Clearview to clear the alarms listed on the Alarm screen. Note that
if an alarm condition continues, the references for that alarm will
continue to appear in the columns.
Print (Alarms)
Click Print to display the print dialog for printing the Alarm screen.
FS Thermocouple break
HP High Process Alarm
HD High Deviation Alarm
LD Low Deviation Alarm
LP Low Process Alarm
(Green) Indicates that the pro-
cess is within its deviation
band.
(Yellow) Indicates that the
process is outside the devia-
tion band.
(Red) A High or Low Process
Alarm is unacknowledged.
(Grey) Alarm has been ac-
knowledged.
