AnaWin User’s Guide 2-1
2
AnaWin Screen
Displays
This chapter describes the features common to most AnaWin screens
and lists the options available from the AnaWin main menu bar.
Screen Conventions
Figure 2-1 shows a typical AnaWin screen.
FIGURE 2-1
AnaWin Screen Conventions
Caption
Minimize/Maximize
Alarm Button/
Indicator
Message box (descrip-
tion of cursor location or
current operation)
Current Time
Communication Status
Main Menu
Name of Last
Recipe Downloaded
Current Group
(if enabled)
Login/Logout
Buttons
Screen
Communicating Controller
