2. Click the arrow button to go to the next window.
3. Click and hold the arrow UP button to fill the tank. The pump turns green and the pipe starts blinking. The
bargraph is yellow when the tank begins to fill and turns blue when it fills more than 25%.
4. When the tank fills above 85% the bargraph turns red.
5. Click and hold the arrow DOWN button to lower the tank level.
6. Right-click in the simulation window and select Exit simulation.
