94 EZware5000 Series Programming Manual
1010-1007, Rev. 10
The object can be configured to handle insufficient security in one of two ways:

The object can be hidden while security is not sufficient.

The HMI can display the message defined as Message 1 in the System Message object.
There are a number of local HMI addresses that can be used with the security features.
Address Description Data Type Notes
LB9050 Reset security level to 0 (no security) Boolean Set momentarily to trigger.
LB9060 Invalid password Boolean Set by the HMI when an invalid password
is entered. Must be explicitly reset.
LB9061 Load new passwords Boolean Loads new passwords as defined
byLW9500-9523
LW9219 User level 16-bit unsigned Set to 1-12. Determines which password
is used.
LW9220 Password 32-bit unsigned Enter password into this address to
change the security level
LW9222 Current access classes 16-bit binary Indicates the Access Classes currently
allowed. Bit 0 indicates Class A; Bit 5
indicates Class F.
