HMI Local Setup 15
1010-1007, Rev. 10
When Download is selected, a dialog will appear requesting the Download password and what data to download.
Password Enter the Download password.
Download project files When checked, the HMI will check the specified folder for project data, and
transfer it if it exists.
Download history files When checked, the HMI will check the specified folder for history data, and
transfer it if it exists (includes data log files, event log files, and recipe files).
Clear history files When checked, clears all history files in the HMI (includes data log files,
event log files, and recipe files).
If a USB flash drive is being used to upload or download a project, select the folder under the usbdisk folder (if the
project was saved on the root of the USB drive) and then click OK. If the project is in a folder on the USB drive, select
the folder just above the MT8000 folder.
