118

EZware5000 Series Programming Manual

1010-1007, Rev. 10

#55:ASCII Small – A style of an ASCII keypad.

#60:ASCII Upper M – A style of an ASCII keypad.

#61:ASCII Lower M – A style of an ASCII keypad.

#62:ASCII Upper S – A style of an ASCII keypad.

#63:ASCII Lower S – A style of an ASCII keypad.

 Not every model uses every keypad listed.

The remaining windows are available to be created as you desire for your project. In order to create new windows,
the following steps must be performed.

To create a new window:

1. From the Window menu, select Open Window. The Open Window dialog box appears.

2. Click New… The Select Window Style dialog box appears.

3. Click Base Window. If the Fast Selection and Common Window buttons appear grayed out, then it is because

those windows have already been created. The Window Setting dialog box appears.
