14 EZware5000 Series Programming Manual
1010-1007, Rev. 10
3. Click on the Version tab to display the current firmware information.
Transferring Projects and Data from USB/CompactFlash
When a USB or Compact Flash device is inserted into the HMI5000 Series, a dialog is displayed. The same dialog is
displayed for transferring projects or data.
 Data is placed on the USB or CF device by EasyBuilder or Project Manager.
Download Transfer data from the USB/CF to the HMI
Upload Transfer data from the HMI to the USB/CF
Restart Project and exit Close the dialog and restart the HMI
Cancel Close the dialog without transferring
Time Remaining The dialog will automatically close after 10 seconds if no selection
is made; shows the time remaining
