17.3 Load Test Plan Number Status Display
LOAD TEST PLAN
NUMBER:
Figure 61.0 Load Test Plan Number Status Display
a. Description: Allows the operator to enter a test plan number to test a transformer. The
pass/fail test requirements for %DIFF are defined in the test plan. This enables the printing
of the pass/fail status of the test.
b. Origin: From the “Test Plan Menu” select menu option 1.
c. Action Options: Enter the test plan number to load by pressing on the key numbers 0
through 9 and pressing “ENTER” or push down on the Control Knob to confirm. Press
“STOP” to abort and return to “Main Menu”. Press “CLEAR” prior to either of the above
actions to enter a different test plan number.
d. Action To Perform: Enter the test plan number 1 for this example by pressing the key
number 1 and pressing “ENTER” or push down on the Control Knob to confirm.
NOTE:
If test plan 1 does not exist, then use any test plan number the operator chooses to load.
