TRI-PHASE OPERATING™ INSTRUCTIONS
102
17.12 Print Test Plan Procedure
Table 16 .0 shows the procedure to perform for printing a transformer test plan stored in FLASH
EEPROM. Transformer test plans contain the transformer nameplate voltages for each test (i.e.,
TAP). The calculated ratios (derived from the transformer name plate voltage) are then compared
with the measured ratios and the percentage error is calculated (i.e., %DIFF). A test report using the
test plan will indicate “PASS” or “FAIL” based on the test plan pass/fail parameters.
Table 16.0 Print Test Plan Procedure
STEP DESCRIPTION DISPLAY ACTION
1 Select “Test Plan” from the
“Main Menu” 1.RUN TEST .
2.SETUP
3.TEST PLAN
4.DIAGNOSTIC
TIME: 20:15:00
DATE: 07/16/08
Press key number 3
Selection of 3 may be
made by turning the
Control Knob. Push
down Control Knob
after 3 is selected
2 Select “Print Test Plan” from the
“Test Plan Menu” 1.LOAD TEST PLAN .
2.UNLOAD TEST PLAN
3.PLAN DIRECTORY
4.PRINT TEST PLAN
5.ERASE TEST PLAN
6.SAVE TEST PLAN
Press key number 4
Selection of 4 may be
made by turning the
Control Knob. Push
down Control Knob
after 4 is selected
3 “Print Test Plan Number” status
display PRINT TEST PLAN
NUMBER: Use keys 0 through 9
to enter test plan
number
4 Confirm test plan number PRINT TEST PLAN
NUMBER: 1 Press “ENTER” key to
confirm
(1 was entered)
5 Return to “Main Menu” 1.RUN TEST .
2.SETUP
3.TEST PLAN
4.DIAGNOSTIC
TIME: 20:15:00
DATE: 07/16/08
None
