TRI-PHASE OPERATING™ INSTRUCTIONS
73
16.13 Print Directory Menu
PRINT DIRECTORY
1.FULL DIRECTORY .
2.SHORT DIRECTORY
Figure 47.0 Print Directory Menu
a. Description: Allows the operator to print a short directory or full directory of test record
headers. Selecting the short directory will print the last ten record headers stored in FLASH
EEPROM. Selecting the full directory will print all test record headers stored in FLASH
EEPROM.
b. Origin: From the “Save/Restore Menu” (Figure 39.0) select menu option 3.
c. Action Options: Press key number 1 to print all the test record headers. Press key number
2 to print the short directory of the last ten test record headers. Selection of number 2 may
be made by turning the Control Knob and pushing down the Control Knob after number 2 is
selected.
d. Action To Perform: Select either menu option 1 or 2.
e. Result of Action: The test record directory is printed and the “Main Menu” is displayed on
the LCD.
