TRI-PHASE OPERATING™ INSTRUCTIONS
83
16.22 Erase Record Menu
ERASE RECORD
1.ERASE SINGLE RECORD .
2.ERASE ALL RECORDS
“STOP” TO EXIT
Figure 55.0 Erase Record Menu
a. Description: Allows the operator to erase a single test record, or erase all test records from
FLASH EEPROM.
b. Origin: From the “Save/Restore Record Menu” (Figure 39.0) select menu option 4.
c. Action Options: Press key number 1 or push down on the Control Knob to select the
“Erase Single Record” option. Press key number 2 to select the “Erase All Records” option.
Selection of number 2 may be made by turning the Control Knob and pushing down the
Control Knob after number 2 is selected. Press the “STOP” key to return to the “Main
Menu”.
d. Action To Perform: Select menu option 1 for this example.
NOTE:
This menu is designed for quick erasing of multiple record numbers without erasing all test records.
After erasing a single test record this menu is displayed again for entry of another test record to be
erased.
