TRI-PHASE OPERATING™ INSTRUCTIONS
77
16.16 Scroll Test Record Menu
RECORDS DIRECTORY
“UP” TO SCROLL FWD
“DWN” TO SCROLL RVS
Figure 49.0 Scroll Test Record Menu
a. Description: Allows the operator to scroll in forward or reverse order through all of the
test records stored in FLASH EEPROM.
b. Origin: This menu is displayed after the operator selects menu option 2 from the “Restore
Record Menu” (Figure 40.0).
c. Action Options:
Pressing the “PAPER V CONTRAST” key displays the first test record header stored in
FLASH EEPROM. Thereafter each instance of pressing the “PAPER V CONTRAST” key
displays the next higher sequential test record header stored in FLASH EEPROM. Pressing
the “PAPER W CONTRAST” key displays the next lower sequential test header stored in
FLASH EEPROM. Pressing “PAPER W CONTRAST” key when the first test record is
displayed will return the LCD display to Figure 49.0.
Pressing the “PAPER W CONTRAST” key displays the last test record header stored in
FLASH EEPROM. Thereafter each instance of pressing the “PAPER W CONTRAST” key
displays the next lower sequential test record header stored in FLASH EEPROM. Pressing
the “PAPER V CONTRAST” key displays the next higher sequential test header stored in
FLASH EEPROM. Pressing “PAPER V CONTRAST” key when the last test record is
displayed will return the LCD display to Figure 49.0
d. Action To Perform: Either option may be selected.
