TRI-PHASE OPERATING™ INSTRUCTIONS

16.11 Save Test Results To A Test Record Procedure

The following procedure allows the operator to save test results to a test record. The operator may
perform one or more transformer tests of an identical transformer configuration, each time saving
the test results in working memory. All of the test results remain in the temporary memory at the
completion of the testing. At that time the operator decides to save all of the test results to a test
record in flash memory and performs the following procedure. This procedure allows the operator
to perform multiple tests quickly without generating a test record for each individual test performed.

Table 8.0

Save Test Results To A Test Record Procedure

STEP DESCRIPTION

DISPLAY

ACTION

Perform one or more
transformer test(s) and save the
test results each time but do not
save the test results to a test
record until all testing is
completed

refer to

Table 5

.0 or to

Table 6

Perform a transformer
test using

Table 5

steps 1 through 11,
steps 12 and 13 are
optional,
save the test results at
step 14
Select menu option 1 or
3 from the “Run
Another Test Menu” at
step 16 of

Table 5

.0 or

step 17 of

Table 6

each time a test is
performed

When no more tests are to be
performed select menu option 2
(“NO”) from the “Run Another
Test Menu” at step 16 of

Table

.0 or step 17 of

Table 6

RUN ANOTHER TEST?

1.YES

2.NO
3. REPEAT PREV. TEST
