17.1 Load a Test Plan and Test a Transformer Procedure (continued)
Table 13.0
Load a Test Plan and Test a Transformer Procedure (continued)
STEP DESCRIPTION
DISPLAY
ACTION
8
“Testing In Progress Status
Display”
TEST IN PROGRESS
PLEASE WAIT…
None
9
“Test Results Status Display”
Observe test results
The three phase test results are
displayed first, then the phase
information for A, B, and C
The single phase test results are
displayed last
SINGLE PHS TEST RSLT:
RATIO mA %DIFF
A+99.985
2.6 0.06
P
B+100.08
1.8 0.16
P
C+99.994
2.4 0.07
P
XFMR TYPE: Dyn1
None
“P” indicates test
passed
Note:
Pass and Fail results
are shown as “P” or
“F” on the LCD.
10
“Test Results Status Display”
Go to next LCD display
SINGLE PHS TEST RSLT:
RATIO mA %DIFF
A+99.985
2.6 0.06
P
B+100.08
1.8 0.16
P
C+99.994
2.4 0.07
P
XFMR TYPE: Dyn1
Press any key or push
down Control Knob
11
“Print Test Results Menu”
Print test result on built-in
printer option
PRINT TEST RESULTS?
1.YES
.
2.NO
Press key number 1 or
push down Control
Knob
12
Select “Column” from the “Print
Format Menu”
PRINT FORMAT
1.COLUMN
.
2.DETAILED
Press key number 1 or
push down Control
Knob
13
“Keep This Reading Menu”
Store test reading in FLASH
EEPROM
KEEP THIS READING?
1.YES
.
2.NO
Press key number 1 or
push down Control
Knob
14
“Test Saved Status Display”
TEST SAVED
Press any key or push
down Control Knob
15
“End of Test Plan Status
Display”
Last test completed from test
plan
END OF TEST PLAN
Press any key or push
down Control Knob
16
“Save This Record Menu”
Save record in FLASH
EEPROM option
SAVE THIS RECORD?
1.YES
.
2.NO
Press key number 1 or
push down Control
Knob
