TRI-PHASE OPERATING™ INSTRUCTIONS
72
16.12 Print Test Record Directory
The following procedure allows the operator to print the directory of test records stored in FLASH
EEPROM.
Table 9.0 Print Test Record Directory Procedure
STEP DESCRIPTION DISPLAY ACTION
1 Select “Setup” from the “Main
Menu” 1.RUN TEST .
2.SETUP
3.TEST PLAN
4.DIAGNOSTIC
TIME: 20:15:00
DATE: 07/16/08
Press key number 2
Selection of 2 may be
made by turning the
Control Knob. Push
down Control Knob
after 2 is selected
2 Select “Save/Restore Record”
from the “Setup Menu” 1.RECORD ID .
2.TEST VOLTAGE
3.TEST FREQUENCY
4.PRINT RECORD
5.SAVE/RESTORE RECORD
6.SET TIME
Press key number 5
Selection of 5 may be
made by turning the
Control Knob. Push
down Control Knob
after 5 is selected
3 Select “Record Directory” from
the “Save/Restore Menu” 1.RESTORE RECORD .
2.SAVE RECORD
3.RECORD DIRECTORY
4.ERASE RECORD
Press key number 3
Selection of 3 may be
made by turning the
Control Knob. Push
down Control Knob
after 3 is selected
4 Select “Short directory” from
the “Print Directory Menu” PRINT DIRECTORY
1.FULL DIRECTORY .
2.SHORT DIRECTORY
Press key number 1 or
push down Control
Knob
OR
Press key number 2.
Selection of 2 may
also be made by
turning the Control
Knob. Push down
Control Knob after 2
is selected
5 Return to “Main Menu” 1.RUN TEST .
2.SETUP
3.TEST PLAN
4.DIAGNOSTIC
TIME: 20:15:00
DATE: 07/16/08
None
