TRI-PHASE OPERATING™ INSTRUCTIONS
35
13.5 Start/Stop Test Status Display
“START” TO TEST
OR
“STOP” TO ABORT
Figure 22.0 Start/Stop Test Status Display
a. Description: Allows the operator to start to test or abort a test.
b. Origin: The LCD displays “Start/Stop Test Status Display” after the operator enters the
nameplate voltage for X (Figure 21.0) or selects 2 on the “Transformer Name Plate Voltage
Menu” (Figure 17.0).
c. Action Options: Press the “START” key to start a test and advance to the “Test In
Progress Status Display” (Figure 23.0). Press the “STOP” key to abort a test and return to
the “Main Menu”.
d. Action To Perform: Press the “START” key to start the test for this example.
