TRI-PHASE OPERATING™ INSTRUCTIONS
76
16.15 Restore Test Record To LCD Procedure (continued)
Restore Test Record To LCD Procedure (continued)
STEP DESCRIPTION
DISPLAY
ACTION
7
“Restored Record Status
Display”
Observe test record displayed on
LCD
#43
07/17/08
07:28:59
1 TESTS
FACTORY
120V
120V
ABC
TEST TRANSFORMER
None
After viewing the test
record header press
“ENTER” or push
down Control Knob to
restore the record
8
“Record Restored Menu”
Record recalled from FLASH
EEPROM to temporary memory
RECORD RESTORED!
PRINT RECORD?
1.YES
.
2.NO
Press key number 1 or
push down on the
Control Knob
9
“Print Record Restored Menu”
Display test record to LCD or
print test record
PRINT RECORD
1.PRINT TO LCD
.
2.PRINT TO PRINTER
Press key number 1 or
push down on the
Control Knob
10
“Restored Record First Status
Display”
SINGLE PHASE
Num Tests: 1
0717/08
07:28:59
FACTORY
120
ABC
TEST TRANSFORMER
Observe first part of
test record displayed
on LCD
Press key number 1 or
push down on the
Control Knob to view
remaining test record
11
“Restored Record Second Status
Display”
1 SINGLE PHASE
40 VOLTS
SINGLE-PHASE RESULTS:
RATIO mA
%DIFF
+10.005
1.9
0.05
Observe second part
of test record
displayed on LCD
Press “STOP” to
return to “Main
Menu”
12
Return to “Main Menu”
1.RUN TEST
.
2.SETUP
3.TEST PLAN
4.DIAGNOSTIC
TIME: 20:15:00
DATE: 07/16/08
None
NOTE:
After viewing the test record, another test record may be viewed by pressing either the
“PAPER
V
CONTRAST” key or the “PAPER
W
CONTRAST” key and repeating steps 5 and 6.
When all desired records have been viewed press “ENTER” to advance to step 8.
