TRI-PHASE OPERATING™ INSTRUCTIONS
48
13.17 Transformer Name Plate Voltage Menu For Another Test
XFMR NAME PLATE VLTG
1.YES
2.NO
3.USE PREVIOUS DATA
Figure 34.0 Nameplate Voltage Selection Menu For Another Test
a. Description: This menu displays when another test is performed. The operator has an
added option to use the same nameplate voltage data from the previous test.
b. Origin: After selecting number 1 (“YES”) from the options listed in “Run Another Test
Menu” (Figure 31.0) the “Transformer Name Plate Voltage Menu” to perform another test
displays.
c. Action Options: Press key number 1 (“YES”) or push down on the Control Knob and
advance to the “Name Plate Voltage” display (Figure 18.0). Press key number 2 to bypass
this option and advance to the “Start/Stop Test Menu” (Figure 22.0). Press key number 3 to
use the same transformer nameplate voltage data from the previous test and advance to the
“Start/Stop Test Menu”. Selection of menu items may also be made by turning the Control
Knob to select a menu option, then pushing down on the Control Knob once the selection is
made.
