TRI-PHASE OPERATING™ INSTRUCTIONS
118
22.0 H And X Cable Diagnostic Test Procedure
The following procedure allows the operator to perform diagnostics on the TRI-PHASE™ H and X
cables.
Table 22.0 H And X Cable Diagnostic Test Procedure
STEP DESCRIPTION DISPLAY ACTION
1 Select “Diagnostic” from “Main
Menu” 1.RUN TEST .
2.SETUP
3.TEST PLAN
4.DIAGNOSTIC
TIME: 20:15:00
DATE: 07/16/08
Press key number 4
Selection of 4 may be
made by turning the
Control Knob. Push
down Control Knob
after 4 is selected
2 Select “Cable Test” from the
“Diagnostic Menu” DIAGNOSTIC
1.CABLE TEST .
2.VERIFICATION TEST
Press key number 1 or
push down Control
Knob
3 Connect cables as instructed in
display CABLE TEST
CONNECT: H0-X0, H1-X1
H2-X2, H3-X3
“ENTER” TO CONTINUE
Press “ENTER” key
after connecting
cables
4 Observe test results CABLE TEST
H0-X0, H1-X1: OK
H0-X0, H2-X2: OK
H0-X0, H3-X3: OK Press any key to or
push down Control
Knob return to “Main
Menu”
“Main Menu” 1.RUN TEST .
2.SETUP
3.TEST PLAN
4.DIAGNOSTIC
TIME: 20:15:00
DATE: 07/16/08
None
NOTE:
A failed diagnostic on the cable test will display “NOT OK”.
