25.9 Load Thumb Drive Test Plan Status Displays
LOAD THUMB DRIVE TP
PLAN_
LOAD THUMB DRIVE TP
PLAN_###
Figure 85.0 Load Thumb Drive Test Plan Status Displays
a. Description: Allows the operator to load a test plan from the thumb drive.
b. Origin: This menu is displayed after the operator selects number 2 (“Thumb Drive”) from
the “Load Test Plan Number With Thumb Drive Menu” (Figure 84.0).
c. Action Options: Enter the test plan to load from the thumb drive into internal memory
using key numbers 0 through 9. Press the “CLEAR” key to enter another number. Press the
“ENTER” key or push down the Control Knob to confirm.
d. Status Displays: The top status displays first. The bottom status display indicates the test
plan number entered by the operator.
