TRI-PHASE OPERATING™ INSTRUCTIONS
110
Table 18.0 Enter Transformer Identification for Test Record Procedure (continued)
STEP DESCRIPTION DISPLAY ACTION
7 Enter Transformer Model MODEL:
TEST TRANSFORMER
↑/↓ TO POSITION
“ENTER” TO ACCEPT
Use the alpha-numeric
keys to enter
Transformer model*
Press “ENTER” key to
confirm
(Single Phase entered)
8 Enter Transformer Serial
Number
SERIAL NUMBER:
7777777
↑/↓ TO POSITION
“ENTER” TO ACCEPT
Use the alpha-numeric
keys to enter
Transformer serial
number*
Press “ENTER” key to
confirm
(1234567890 entered)
9 Enter Transformer KVA rating KVA RATING:
500KVA
↑/↓ TO POSITION
“ENTER” TO ACCEPT
Use the alpha-numeric
keys to enter
Transformer KVA
rating*
Press “ENTER” key to
confirm
(500 entered)
10 Enter Operator name OPERATOR:
DAVE
↑/↓ TO POSITION
“ENTER” TO ACCEPT
Use the alpha-numeric
keys to enter the
Operator name
performing test*
Press “ENTER” key to
confirm
(Hai Nguyen entered)
11 Return to “Main Menu” 1.RUN TEST .
2.SETUP
3.TEST PLAN
4.DIAGNOSTIC
TIME: 20:15:00
DATE: 07/16/08
None
* see note
NOTE:
Press the V (moves cursor to right) and/or W (moves cursor to left) keys to position the cursor in
the proper location in the line.
Successively pressing a key on the keypad will cycle through the characters
on the key’s legend and display it at the cursor location.
