TRI-PHASE OPERATING™ INSTRUCTIONS
38
13.8 Print Test Results Menu
PRINT TEST RESULTS?
1.YES
2.NO
Figure 25.0 Print Test Results Menu
a. Description: The TRI-PHASE™ has the capability to print the current test results
(displayed on the LCD screen) using the built-in thermal printer.
b. Origin: The “Print Test Results Menu” is displayed after operator presses any key or
pushes down on the Control Knob from the “Test Result Status Display” (Figure 24.0).
c. Action Options: Press key number 1 (“YES”) or push down the Control Knob to advance
to the “Print Format Menu” (Figure 26.0). Press key number 2 to advance to “Keep This
Reading Menu” (Figure 29.0). Number 2 may be selected by turning the Control Knob,
then pushing down on the Control Knob after 2 is selected.
d. Action To Perform: Select menu option 1 for this example.
13.9 Print Format Menu
PRINT FORMAT?
1.COLUMN
2.DETAILED
Figure 26.0 Print Format Menu
a. Description: Allows the operator to select which format to use for printing the test results.
Refer to Figure 27.0 for a typical column format printout. Refer to Figure 28.0 for a
detailed format printout.
b. Origin: This menu is displayed after the operator selects 1 (“YES”) from the “Print Test
Results Menu” (Figure 25.0).
c. Action Options: Press key number 1 or push down on the Control Knob to select the
column format print out of the test results. Press key number 2 to select the detail format
printout of the test results. Number 2 may be selected by turning the Control Knob, then
