TRI-PHASE OPERATING™ INSTRUCTIONS
67
16.8 Print Format Menu
PRINT FORMAT?
1.COLUMN .
2.DETAILED
Figure 44.0 Print Format Menu
a. Description: Allows the operator to select which format to use for printing the test record.
Refer to Figure 45.0 for a typical test record column format printout. Refer to Figure 46.0
for a typical test record detailed format printout.
b. Origin: This menu is displayed after the operator selects menu option 2 from the “Print
Record Menu” (Figure 43.0 Print Record Menu).
c. Action Options: Press key number 1 or push down the Control Knob to select the column
format. Press key number 2 for detail format or by turning the Control Knob and push down
the Control Knob after number 2 is selected.
d. Action To Perform: Either menu option 1 or 2 from step c may be selected.
e. Results of Action Performed: Once the print format is selected the test report is printed
and the LCD displays the following status message momentarily, then displays the “Main
Menu”.
PLEASE WAIT…
PRINTING REPORT
