TRI-PHASE OPERATING™ INSTRUCTIONS
86
16.25 Erase All Test Records Procedure
The following procedure allows the operator to erase all test records from FLASH EEPROM.
Table 12.0 Erase All Test Records Procedure
STEP DESCRIPTION DISPLAY ACTION
1 Select “Setup” from the “Main
Menu” 1.RUN TEST .
2.SETUP
3.TEST PLAN
4.DIAGNOSTIC
TIME: 20:15:00
DATE: 07/16/08
Press key number 2
Selection of 2 may be
made by turning the
Control Knob. Push
down Control Knob
after 2 is selected
2 Select “Save/Restore Record”
from the “Setup Menu” 1.RECORD ID .
2.TEST VOLTAGE
3.TEST FREQUENCY
4.PRINT RECORD
5.SAVE/RESTORE RECORD
6.SET TIME
Press key number 5
Selection of 5 may be
made by turning the
Control Knob. Push
down Control Knob
after 5 is selected
3 Select “Erase Record” from the
“Save/Restore Menu” 1.RESTORE RECORD .
2.SAVE RECORD
3.RECORD DIRECTORY
4.ERASE RECORD
Press key number 4
Selection of 4 may be
made by turning the
Control Knob. Push
down Control Knob
after 4 is selected
4 Select “Erase All Records” from
the “Erase Record Menu” ERASE RECORD
1.ERASE SINGLE RECORD .
2.ERASE ALL RECORDS
“STOP” TO EXIT
Press key number 2 or
push down on the
Control Knob
5 Confirm that all records are to be
erased ERASE ALL RECORDS!
Are you SURE?
“ENTER” TO CONTINUE.
Press “ENTER” to
confirm
6 Records being erased from
FLASH EEPROM ERASING RECORDS
PLEASE WAIT…
Wait for next display
7 All records erased from FLASH
EEPROM confirmation RECORDS ERASED! Press any key or push
down Control Knob
9 Return to “Main Menu” 1.RUN TEST .
2.SETUP
3.TEST PLAN
4.DIAGNOSTIC
TIME: 20:15:00
DATE: 07/16/08
