18.0 Entering Test Record Identification Information Procedure
The following procedure allows the operator to enter transformer identification information for the
test record ID. This information is printed on each test record printout.
Table 18.0 Entering Test Record Identification Information Procedure
STEP DESCRIPTION DISPLAY ACTION
1 Select “Setup” from “Main
Menu” 1.RUN TEST .
2.SETUP
3.TEST PLAN
4.DIAGNOSTIC
TIME: 20:15:00
DATE: 07/16/08
Press key number 2
Selection of 2 may be
made by turning the
Control Knob. Push
down Control Knob
after 2 is selected
2 Select “Record ID” 1.RECORD ID .
2.TEST VOLTAGE
3.TEST FREQUENCY
4.PRINT RECORD
5.SAVE/RESTORE RECORD
6.SET TIME
Press key number 1 or
push down Control
Knob
3 Enter Company name COMPANY:
VANGUARD INSTRUMENTS
↑/↓ TO POSITION
“ENTER” TO ACCEPT
Use the alpha-numeric
keys to enter
Company name*
Press “ENTER” key to
confirm
(Vanguard
Instruments entered)
4 Enter Substation name STATION:
FACTORY
↑/↓ TO POSITION
“ENTER” TO ACCEPT
Use the alpha-numeric
keys to enter
Substation name*
Press “ENTER” key to
confirm
(Factory entered)
5 Enter Circuit name CIRCUIT:
120V
↑/↓ TO POSITION
“ENTER” TO ACCEPT
Use the alpha-numeric
keys to enter Circuit
name*
Press “ENTER” key to
confirm
(120V entered)
6 Enter Manufacturer name MANUFACTURER:
ABC
↑/↓ TO POSITION
“ENTER” TO ACCEPT
Use the alpha-numeric
keys to enter
transformer
manufacturer name*
Press “ENTER” key to
confirm
(ABC entered)
