TRI-PHASE OPERATING™ INSTRUCTIONS
84
16.23 Erase Record Status Display
ERASE RECORD
NUMBER:
Figure 56.0 Erase Record Status Display
a. Description: Allows the operator to enter the test record number to be erased.
b. Origin: From the “Erase Record Menu” (Figure 55.0) select menu option 1.
c. Action Options: Enter the record number to erase by pressing on the key numbers 0
through 9 and pressing “ENTER” or push down Control Knob to confirm. When an
incorrect number is pressed, pressing “CLEAR” before pressing “ENTER” clears the
number displayed and allows for another number to be keyed in.
d. Action To Perform: Press key number 5 then key number 0 (i.e., 50 displayed), then press
“ENTER” for this example.
e. Results Of Action: After confirming the record number to be erased the following
message is displayed:
ERASEING RECORD
PLEASE WAIT…
NOTES:
The following message will display when a record is not found in FLASH EEPROM memory.
“RECORD NUMBER ##
NOT FOUND!
where ## is the test record number that was entered
then “Main Menu” is displayed
If test record 50 does not exist, then use any record number the operator chooses to erase.
