Page 21
TRI-PHASE OPERATING™ INSTRUCTIONS
12.2 Typical Cable Connections to a Delta-Wye Transformer (continued)
21
LTC Control Cable
X Cable
H Cable
Power Cable
Gnd Cable
Figure 3.0 Typical Front Panel Cable Connectors
H Cable Connections
X Cable Connections
Figure 4.0 Typical H & X Cable Connections to Delta-Wye Transformer
