TRI-PHASE OPERATING™ INSTRUCTIONS
81
16.20 Restored Record Status Displays
SINGLE PHASE
Num Tests: 1
07/17/08 07:28:59
FACTORY
120
ABC
TEST TRANSFORMER
Figure 53.0 Restored Record First Status Display
1 SINGLE PHASE
40 VOLTS 60 Hz
SINGLE-PHASE RESULTS:
RATIO
mA %DIFF
+10.005 1.9 0.05
Figure 54.0 Restored Record Second Status Display
a. Description: The test record is displayed on the LCD in two displays.
b. Origin: Selecting menu option 1 (“YES”) from the “Print Record Restored Menu” (Figure
52.0).
c. Action To Perform: Observe the first status display of the test record on the LCD, then
press key number 1 or push down the Control Knob. Observe the second status display of
the test record on the LCD, then press the “STOP” button.
