TRI-PHASE OPERATING™ INSTRUCTIONS
121
25.0 USB FLASH Thumb Drive
With the USB FLASH thumb drive inserted many of the operational menus described in this
manual will contain an extra option to select the thumb drive. When this option is selected, the
submenus will allow for selection of the internal FLASH EEPROM memory or the thumb drive
FLASH memory. The following paragraphs describe each menu that has these added options and
their related status displays.
25.1 Save/Restore Record With Thumb Drive Menu
1.RESTORE RECORD .
2.SAVE RECORD
3.RECORD DIRECTORY
4.ERASE RECORD
5.COPY TO THUMB DRIVE
Figure 77.0 Save/Restore Record With Thumb Drive Menu
a. Description: Allows the operator to restore a test record, save a test record, print a
directory of test records, erase a single test record or all test records, or copy test record(s)
to the thumb drive.
b. Origin: From the “Setup Menu” (Figure 38.0) select menu option 4.
c. Action Options: Press key number 1 or push down the Control Knob to select the “Restore
Record Menu”. Press key number 2 to select the “Save Record Menu”. Press key number 3
to select the “Record Directory Menu”. Press key number 4 to select the “Erase Record
Menu”. Press key number 5 to select the “Copy To Thumb Drive” record menu. Selection
of 2, 3, 4, or 5 may be made by turning the Control Knob to the desired number and
pushing down the Control Knob after it is selected.
NOTE:
When test record(s) is/are saved to or copied to the thumb drive a new folder is added to the root
directory of the thumb drive. The name of this folder is VANGUARD. The test record(s) that were
saved or copied are contained in this new folder in a sub-folder named TRI-PHS.
