TRI-PHASE OPERATING™ INSTRUCTIONS
15
6.1 Cable Marking and Identification
Both the H and X cable test leads are terminated with heavy-duty battery clips. Test cable leads are
identified as follows.
Table 3.0 Cable Markings and Identification
Test Cable Name Transformer Terminals Clip Color Identification
Single Phase H Cables H1 Red H1/1U/A
Single Phase H Cables H2 Red H2/1V/B
Single Phase X Cables X1 Black X1/2U/a
Single Phase X Cables X2 Black X2/2V/b
Three Phase H Cables H0 Red H0/1N/n
Three Phase H Cables H1 Red H1/1U/A
Three Phase H Cables H2 Red H2/1V/B
Three Phase H Cables H3 Red H3/1W/C
Three Phase X Cables X0 Black X0/2N/n
Three Phase X Cables X1 Black X1/2U/a
Three Phase X Cables X2 Black X2/2V/b
Three Phase X Cables X3 Black X3/2W/c
LTC Cable RAISE (two connections) Green RAISE
LTC Cable LOWER (two connections) White LOWER
