TRI-PHASE OPERATING™ INSTRUCTIONS
31
13.1 Main Menu
1.RUN TEST
2.SETUP
3.TEST PLAN
4.DIAGNOSTIC
TIME: 20:15:05
DATE: 07/16/08
Figure 14.0 Main Menu
a. Description: The “Main Menu” (i.e., “start-up”) provides selection of the primary
functions of the TRI-PHASE™. These functions consist of one or more sub-menus that
allow the operator to test a transformer, select various settings or options, select test plan
options, or perform diagnostics on the TRI-PHASE™.
b. Origin: The “Main Menu” displays on the LCD after power is applied to the TRI-
PHASE™.
c. Action Options:
Press key number 1 to select “Run Test”
Press key number 2 to select “Setup”
Press key number 3 to select “Test Plan Menu”
Press key number 4 to select “Diagnostic”
Selection may also be made by turning the Control Knob to select a menu option and then
pushing down on the Control Knob once the selection is made.
d. Action To Perform: Select menu option 1 for this example.
NOTES:
Real time and date is displayed at the bottom of LCD screen.
Refer to section 11.1 for LCD contrast control operation.
To return to the “Main Menu” at any time press “STOP” on the keypad.
