TRI-PHASE OPERATING™ INSTRUCTIONS
100
17.10 Print Test Plan Directory Procedure
The following procedure allows the operator to print the test plan directory stored in FLASH
EEPROM non-volatile memory.
Table 15.0 Print Test Plan Directory Procedure
STEP DESCRIPTION DISPLAY ACTION
1 Select “Test Plan” from the
“Main Menu” 1.RUN TEST .
2.SETUP
3.TEST PLAN
4.DIAGNOSTIC
TIME: 20:15:00
DATE: 07/16/08
Press key number 3
Selection of 3 may be
made by turning the
Control Knob. Push
down Control Knob
after 3 is selected
2 Select “Plan Directory” from the
“Test Plan Menu” 1.LOAD TEST PLAN .
2.UNLOAD TEST PLAN
3.PLAN DIRECTORY
4.PRINT TEST PLAN
5.ERASE TEST PLAN
6.SAVE TEST PLAN
Press key number 3
Selection of 3 may be
made by turning the
Control Knob. Push
down Control Knob
after 3 is selected
4 Return to “Main Menu” 1.RUN TEST .
2.SETUP
3.TEST PLAN
4.DIAGNOSTIC
TIME: 20:15:00
DATE: 07/16/08
Return to “Main
Menu”
NOTE:
The test plan directory is immediately printed after selecting menu option 3.
