Summit T3‐8 PCI Express Multi‐Lane Protocol Analyzer User Manual 5
Chapter 2
Hardware Description
The PCI Express™ system features Summit Analyzers.
2.1 System Components
 Summit T3‐8 analyzer system
 AC Power Cable
 USB and Ethernet cables
 PETracer Software program CD‐ROM
 (optional) probes and interposers ( see “Adding Devices Manually” on page 11 )
2.2 Host Machine Requirements
The Summit T3‐8 connects to host machine. Please consult the readme file on the
installation CD for the latest host machine requirements.
2.3 Summit T3-8 Front Panel Description
When powered on, the Summit T3‐8 activates the user‐accessible controls and LEDs on
the front panel.
WARNING: Do not open the enclosure. There are no operator serviceable parts inside.
Refer servicing to Teledyne LeCroy.
The controls and LEDs are:
 Power Switch (black): 1 = On and 0 = Off. Once the analyzer is powered off you
need to wait at least 10 seconds before you power it back on, otherwise the ana‐
lyzer may not initialize properly.
 UPSTREAM [7:0] connector: Connection to the probe for the capture of
upstream direction of the link.
 Speed LEDs: Indicate the current speed for the Upstream and Downstream link:
2.5 GT/s, 5 GT/s, or 8 GT/s.
 LCD Menus: Allow you to set up the Summit T3‐8 and view status.
 LCD Menu Navigation Buttons: Allow you to navigate through the LCD menu.
 DOWNSTREAM [7:0] connector: Connection to the probe for the capture of
downstream direction of the link.
