Summit T3‐8 PCI Express Multi‐Lane Protocol Analyzer User Manual 1
Chapter 1
Overview
Designed for developers and validators, the Teledyne LeCroy Summit T3‐8™ is a Gen1/
Gen2/Gen3 PCI Express™ advanced verification system.
By leveraging years of experience in protocol analysis tools for emerging markets, Summit
T3‐8 blends sophisticated functionality with practical features to speed the development
of PCI Express IP cores, semiconductors, bridges, switches, add‐in boards, and systems.
1.1 PETracer Analyzer Hardware and Software
Features and Benefits
Summit T3‐8 Analyzer has these features and benefits:
Features Benefits
Powerful and Intuitive
CATC Trace™ Analysis
Software Faster interpretation and debug of PCI Express traffic
with color‐coded, clearly labeled protocol elements in
a graphical display.
Extensive Decoding Complete, accurate and reliable decoding of TLPs
(Transaction Layer Packets), DLLPs (Data Link Layer
Packets), NVMe, PQI, AHCI and ATA command
transactions and all PCI Express Primitives.
Intelligent Reporting Quickly identify and track error rates and abnormal
link or timing conditions. Display configuration space
and protocol specification details.
Sophisticated Viewing View Packet, Link, Split, NVMe, PQI, AHCI protocol
and ATA command transaction levels of the
PCI Express protocol. Collapsible/expandable headers
with Tool tip explanations make it easy to navigate
and interpret packet contents, headers, and
commands. View packets, transactions of TLPs and
DLLPs in classic CATC Trace™ format or in raw
bit stream for deeper analysis.
4 GB Recording Capacity,
2 GB in each direction Capture long recording sessions for analysis and
problem solving.
