Teledyne LeCroy WavePro Automation Command - Manual (Page 642)

Automation Command and Query Reference Manual - Processor Reference
Greater
GreaterOrEqual
InRange
NotEqual
OutRange
Smaller
SmallerOrEqual
AddressValue BitPattern
MaxBits=32 NumBits=8 NumBytes=1 AllowedBitValues=01X PaddingChar=X
PadAlign=Left SizeAlign=BitFix Format=Ehex Range
AddressValue2 BitPattern
MaxBits=32 NumBits=8 NumBytes=1 AllowedBitValues=01 PaddingChar=1
PadAlign=Left SizeAlign=BitFix Format=Ehex Range
FilterType Enum
Values
Any
ID
IDData
PatternBitLength Integer
From 1 to 128 step 1 Range
PatternBitPos Integer
From 0 to 127 step 1 Range
PatternOperator Enum
Values
Equal
Greater
GreaterOrEqual
InRange
NotEqual
OutRange
Smaller
SmallerOrEqual
PatternValue BitPattern
MaxBits=128 NumBits=8 NumBytes=1 AllowedBitValues=01X PaddingChar=X
PadAlign=Left SizeAlign=BitVar Format=Ehex Range
2-143
918501 RevA
