Automation Command and Query Reference Manual - Control Reference
UseGrid String
Any number of characters Range
SDA2 software does not attempt to display the reference clock. To display the reference clock,we
recommend you use this as the source of a Zoom or Math function, then the view of the Zoom or Math
can be controlled from the graphical user interface. However, it is possible to set UseGrid (this
control) to "YT1" (the first = top left grid) and set "View" to True, to establish a view of the reference
clock. Since SDA2 is not managing this view, it is up to you to turn it off.
Description
View Bool
Sets/Queries the trace's 'Viewed' state. When true, the trace is displayed on one of the display
graticules. Note that even when a trace is not visible, it may be used as a source for Math, Measure,
etc.
Description
ViewLabels Bool
Sets/Queries whether the user-defined labels for the trace are visible.
See Also: LabelsPosition and LabelsText controls.
Description
RESULT app.SDA2.RefClkInput.SDARefClk.Out.Result
SDASTATUS app.SDA2.SDAStatus
DataSource Enum
Values
C1
C2
C3
C4
F1
F2
F3
F4
F5
F6
F7
F8
M1
DataSource Enum
SignalFrequency Double
1-371
918501 RevA
