UseRefClk Bool
If UseRefClk is set to true, then the clock is not derived from the data signal, instead it is derived from
a separate reference clock signal. This corresponds to the "Use Explicit Clock Ref" checkbox on the
Clock Recovery dialog page. If UseRefClk is set to true, the RefClkSlope, Deskew and
FrequencyMultiplier controls are active. (See app.SDA2.RefClkInput for Deskew and
FrequencyMultiplier).
Description
EYEMEASURE app.SDA2.EyeMeasure
Under EyeMeasure are controls for the eye diagrams, iso BER, masks, and mask testing.
BitsInLocator DoubleLockstep
From 1 to 100 step 0.05, locked to 1 2 5, fine grain allowed=true, on=false Range
BitsInLocator DoubleLockstep
EyeMode Enum
FailedList Enum
FailedListEye2 Enum
FailedSymbolsFilter Enum
LogBERmax Double
LogBERmin Double
MaxFailures Integer
SetToCenter Action
ShowEyeMeasure Bool
ShowFailLocation Bool
ShowIsoBER Bool
ShowMask Bool
ShowMaskFailures Bool
ShowSimpleEye Bool
SliceWidth Integer
StopOnFail Bool
