Automation Command and Query Reference Manual - Control Reference
MSxxLogicFamily3
Enum
Values
CMOS2.5V
CMOS3.3V
CMOS5V
ECL
LVDS
PECL5V
TTL
UserDefined
MSxxThreshold0
Double
From 1.5 to 1.5 step 0.02
Range
If you select User Defined Logic Family, then you will be able to define the voltage level of threshold.
The threshold level determines how the input signal is interpreted. Input voltages less than the
threshold are converted to '0'. Input voltages greater than the threshold are converted to '1'.
Description
MSxxThreshold1
Double
From 1.5 to 1.5 step 0.02
Range
MSxxThreshold2
Double
From 1.5 to 1.5 step 0.02
Range
MSxxThreshold3
Double
From 1.5 to 1.5 step 0.02
Range
DIGITALX
app.LogicAnalyzer.Digitalx
BusName
String
Digital0
Bool
Digital1
Bool
Digital2
Bool
Digital3
Bool
Digital4
Bool
Digital5
Bool
Digital6
Bool
Digital7
Bool
Digital8
Bool
DisplayMode
Enum
LineHeight
Double
LineNames
String
PersistDotJoined
Bool
UseGrid
String
