Automation Command and Query Reference Manual - Control Reference
PersistenceTime Enum
Sets/Queries the state of the Persistence Time control. Controls the persistence decay time for this
trace. See the general description above for a discussion of the locked and unlocked persistence
modes.
Description
Values
0.5s
10s
1s
20s
2s
5s
Infinite
ShowLastTrace Bool
Sets/Queries the state of the Show Last Trace control. If True then when this trace is displayed in
persistence mode the last acquired waveform will be superimposed on the accumulating persistence
map.
See the general description above for a discussion of the locked and unlocked persistence modes.
Description
UseGrid String
Any number of characters Range
SDA2 software sets this control to place the peak threshold on the same grid as the jitter spectrum.
Do not set this control.
Description
View Bool
Sets/Queries the trace's 'Viewed' state. When true, the trace is displayed on one of the display
graticules. Note that even when a trace is not visible, it may be used as a source for Math, Measure,
etc.
Description
ViewLabels Bool
Sets/Queries whether the user-defined labels for the trace are visible.
See Also: LabelsPosition and LabelsText controls.
Description
RESULT app.SDA2.JitterMeasure.Spectrum.PkThresh.Out.Result
ZOOM app.SDA2.JitterMeasure.Spectrum.PkThresh.Zoom
HorPos Double
1-327
918501 RevA
