Automation Command and Query Reference Manual - Processor Reference
Aperture
Double
From 0 to 100 step 0.1
Range
For eye-diagram parameters which have an "aperture" setting, this defines the region over which the
eye digrams vertical information is analyzed.
It specifies the percentage of the central region of the eye (relative to 1 Unit Interval) which is used in
the analysis.
Description
Level
Enum
Defines the level for which the peak noise is computed, One or Zero.
Description
Values
One
Zero
EYEQFACTOR
app.Measure.Px.Operator (ParamEngine = "EyeQFactor")
Aperture
Double
From 0 to 100 step 0.1
Range
For eye-diagram parameters which have an "aperture" setting, this defines the region over which the
eye digrams vertical information is analyzed.
It specifies the percentage of the central region of the eye (relative to 1 Unit Interval) which is used in
the analysis.
Description
CursorDisplay
Enum
Set/Query the CursorDisplay cvar. This defines whether the source trace is annotated with 'Help
Markers' generated by the measurement.
Description
Values
Detailed
Off
Simple
Aperture
Double
CursorDisplay
Enum
EYERISETIME
app.Measure.Px.Operator (ParamEngine = "EyeRiseTime")
