Automation Command and Query Reference Manual - Control Reference
UseGrid String
Any number of characters Range
The SDA2 software sets this control so that the CDF will appear on the same grid as the RjBUj
histogram. You should not change this setting.
Description
View Bool
Sets/Queries the trace's 'Viewed' state. When true, the trace is displayed on one of the display
graticules. Note that even when a trace is not visible, it may be used as a source for Math, Measure,
etc.
Description
ViewLabels Bool
Sets/Queries whether the user-defined labels for the trace are visible.
See Also: LabelsPosition and LabelsText controls.
Description
RESULT app.SDA2.JitterMeasure.Histogram.CDFnq.Out.Result
CDFSP app.SDA2.JitterMeasure.Histogram.CDFsp
CDFsp is the CDF computed using the spectral jitter decomposition. When the jitter decomposition method selected
is Spectral, CDFsp is shown when ShowCDF is True. See app.SDA2.JitterMeasure.Histogram.CDFTotal. (Due to a
bug, in firmware 6.0 and previous, when in Spectral jitter decomposition CDFdd was shown). CDFsp can be viewed
at any time by assigning it as the source of a zoom.
AxisXRotation Integer
AxisXRotation Integer
AxisYRotation Integer
ClearSweeps Action
LabelsPosition String
LabelsText String
Persist3DQuality Enum
PersistDotJoined Bool
Persisted Bool
Persistence3d Bool
PersistenceMonoChrome Bool
PersistenceSaturation Integer
PersistenceTime Enum
ShowLastTrace Bool
UseGrid String
View Bool
ViewLabels Bool
1-264
918501 RevA
