Automation Command and Query Reference Manual - Processor Reference
Aperture Double
From 0 to 100 step 0.1 Range
For eye-diagram parameters which have an "aperture" setting, this defines the region over which the
eye digrams vertical information is analyzed.
It specifies the percentage of the central region of the eye (relative to 1 Unit Interval) which is used in
the analysis.
Description
CalcType Enum
Extinction ratio units.
Description
Values
db
linear
pct
CursorDisplay Enum
Set/Query the CursorDisplay cvar. This defines whether the source trace is annotated with 'Help
Markers' generated by the measurement.
Description
Values
Detailed
Off
Simple
CalcType Enum
CursorDisplay Enum
EYEAMPLITUDE
app.Measure.Px.Operator (ParamEngine = "EyeAmplitude")
Aperture Double
From 0 to 100 step 0.1 Range
For eye-diagram parameters which have an "aperture" setting, this defines the region over which the
eye digrams vertical information is analyzed.
It specifies the percentage of the central region of the eye (relative to 1 Unit Interval) which is used in
the analysis.
Description
Aperture Double
CursorDisplay Enum
