Automation Command and Query Reference Manual - Control Reference
VerZoom
Double
From 0.1 to 100 step (8 digits)
Range
Vertical Zoom setting. Locked to a 1, 2, 5 sequence unless VariableVerZoom is set to True .
Description
PCIE
app.SDA2.PCIe
PCIeMask
Enum
Selects the appropriate mask. The user should select the mask based on where the connection to the
signal is.
Description
Values
RXAddInConn
RXPkgPins
RXSysConn
TXAddInConn
TXPkgPins
TXSysConn
PCIeMeasurement
Enum
SDA2 has several sets of measurments from the PCIE Base spec. Most of these measurements are
not included in compliance testing. Some of these measurements may require probing at the TX pins
(or using the software option EyeDr2 to de-embed the fixture). See also ShowPCIeMeasure, below.
Description
Values
LanesSkew
None
SSC
Timing
Voltage
PCIeMask
Enum
PCIeMeasurement
Enum
PCIeStandard
Enum
ShowPCIeMeasure
Bool
