Automation Command and Query Reference Manual - Control Reference
ShowPeakTable Bool
If TRUE, the table of detected peaks, and their respective amplitudes, is shown beside the spectral
plot.
Description
Source Enum
Define the Source trace. Note that only acquisition channels may be used as sources to the spectrum
analyzer.
Description
Values
C1
C2
C3
C4
SpanFreq Double
From 100 to 1e+010 step 100 Range
Define the Span Frequency, valid when the SpanMode control is in CenterSpan mode.
Description
SpanMode Enum
Define the way in which the span of the spectrum is controlled, either as a Center and Span
frequency, or as a Start and Stop frequency.
Description
Values
CenterAndSpan
StartAndStop
VerticalScale DoubleLockstep
From 0.1 to 100 step 0.2, locked to 1 2 5, fine grain allowed=false, on=false Range
Define the vertical scale of the spectrum, in units of dB.
Description
Window Enum
Define the window function used to compute the FFT of the input signal.
Description
Values
BlackmanHarris
FlatTop
Hamming
VonHann
SPECAN app.SpecAnalyzer.SpecAn
1-448
918501 RevA
