Automation Command and Query Reference Manual - Control Reference
VerZoom Double
From 0.1 to 100 step (8 digits) Range
Vertical Zoom setting. Locked to a 1, 2, 5 sequence unless VariableVerZoom is set to True .
Description
PARAMETERS app.SDA2.JitterMeasure.Parameters
BERPow10 Integer
From -16 to -1 step 1 Range
This control corresponses to the control labeled "log10 BER" on the Jitter Paremeters right side
dialog. This value specifies the probability (of error) at which TJ should be calculated.
Description
ClearJitterParams Action
This action control corresponds to the button "Turn Off All" on the Jitter Parameters right side dialog.
It sets False all the cvars in this group with names starting "Show". They are ShowDCD, ShowDDj,
ShowISI, ShowBitRate, and ShowPj.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
app.SDA2.JitterMeasure.Parameters.ClearJitterParams
Example
BERPow10 Integer
ClearJitterParams Action
JitterModel Enum
ShowBitrate Bool
ShowDCD Bool
ShowDDj Bool
ShowISI Bool
ShowPj Bool
1-284
918501 RevA
