Automation Command and Query Reference Manual - Control Reference
BufferSize
Integer
From 200 to 50000 step 1
Range
Size of the buffer which stores incoming parameter values, ready to be histogrammed.
Not to be confused with the 'Values' control, which defines the number of values from the buffer which
are currently rendered in the histogram.
Description
Center
Double
From -1e+010 to 1e+010 step 1e-012
Range
Defines the value of the bin which is centered horizontally within the graticule.
Description
ClearSweeps
Action
Clear any accumulated result data. Useful for example to restart an average, or parameter statistics.
Description
FindScale
Action
Automatically determine an appropriate horizontal scale for the histogram, using the values currently
in the histogram buffer.
Description
HorScale
DoubleLockstep
From 1e-012 to 1e+012 step 0.01, locked to 1 2 5, fine grain allowed=false, on=false
Range
Horizontal scale of the histogram, per division of the graticule.
Description
Values
Integer
From 20 to 2000000000 step 1
Range
Size of the buffer in which all values currently histogrammed are queued.
Description
VerScaleType
Enum
Vertical Scale mode of the histogram, Linear, or 'Linear with Constant Maximum'.
Description
Values
LinConstMax
Linear
RESULT
app.WaveScan.ScanHisto.Out.Result
ZOOM
app.WaveScan.ScanHisto.Zoom
