Automation Command and Query Reference Manual - Processor Reference
eye digrams vertical information is analyzed.
It specifies the percentage of the central region of the eye (relative to 1 Unit Interval) which is used in
the analysis.
Output Enum
Values
db
linear
pct
EYEZEROLEVEL
app.Measure.Px.Operator (ParamEngine = "EyeZeroLevel")
Aperture Double
From 0 to 100 step 0.1 Range
For eye-diagram parameters which have an "aperture" setting, this defines the region over which the
eye digrams vertical information is analyzed.
It specifies the percentage of the central region of the eye (relative to 1 Unit Interval) which is used in
the analysis.
Description
Aperture Double
FALLATLEVEL
app.Measure.Px.Operator (ParamEngine = "FallAtLevel")
HighPct Double
From 10 to 95 step 1 Range
High level in percent.
Description
HighPct Double
LevelsAre Enum
LowPct Double
SetLevel1090 Action
SetLevel2080 Action
