Automation Command and Query Reference Manual - Control Reference
HorPos Double
From -0.5 to 0.5 step (8 digits) Range
Sets/Queries the horizontal position of center of the grid on the zoomed trace Mx. The unit of
measurement is the screen width, that is, 0.3 means a shift of three of the ten divisions. A positive
value moves the trace to the left.
Description
HorZoom Double
From 0.1 to 1e+006 step (8 digits) Range
Sets/Queries the horizontal magnification of the trace Mx. The magnification will be in a 1 2 5 10
sequence unless variable horizontal magnification has been set.
Description
NumSelectedSegments DoubleLockstep
From 1 to 1 step 1, locked to 1 2 5, fine grain allowed=true, on=false Range
VariableHorZoom Bool
Sets/Queries the ability to zoom horizontally by a continuously variable factor as opposed to a factor
that follows a 1, 2, 5 sequence.
Description
VariableVerZoom Bool
Sets/Queries the ability to zoom vertically by a continuously variable factor as opposed to a factor that
follows a 1, 2, 5 sequence.
Description
VerPos Double
From -1.5 to 1.5 step (8 digits) Range
Sets/Queries the vertical position of center of the grid on the zoomed trace Mx. The unit of
measurement is the screen height, that is, 0.375 means a shift of three of the eight divisions. A
positive value moves the trace downwards.
Description
VerZoom Double
From 0.1 to 100 step (8 digits) Range
Sets/Queries the vertical magnification of the trace Mx. The magnification will be in a 1 2 5 10
sequence unless variable vertical magnification has been set.
Description
PASSFAIL app.PassFail
Names of the forms app.PassFail("Qremote").xxxx and app.PassFail("Qx").xxxx are aliases of simpler names which
are described in this section of the manual. Examples of alias pairs are as follows -
app.PassFail.PassFail("Qremote").Operator is equivalent to app.PassFail.Qremote.Operator
app.PassFail.PassFail("Qx").Out.Result is equivalent to app.PassFail.Qx.Out.Result
Please see under app.Acquisition.Channels("Cx") for a programming example.
ActionOn Enum
1-180
918501 RevA
