Automation Command and Query Reference Manual - Processor Reference
PatternBitLength Integer
From 1 to 128 step 1 Range
PatternBitPos Integer
From 0 to 127 step 1 Range
PatternOperator Enum
Values
Equal
Greater
GreaterOrEqual
InRange
NotEqual
OutRange
Smaller
SmallerOrEqual
PatternValue BitPattern
MaxBits=128 NumBits=8 NumBytes=1 AllowedBitValues=01X PaddingChar=X
PadAlign=Left SizeAlign=BitVar Format=Ehex Range
PatternValue2 BitPattern
MaxBits=128 NumBits=8 NumBytes=1 AllowedBitValues=01 PaddingChar=1
PadAlign=Left SizeAlign=BitVar Format=Ehex Range
ViewingMode Enum
Values
Binary
Hex
DELTAPERIODATLEVEL
app.Measure.Px.Operator (ParamEngine = "DeltaPeriodAtLevel")
FindLevel Action
GroupSize Integer
Hysteresis Double
LevelType Enum
PercentLevel Double
SignalType Enum
Slope Enum
StartCycle Integer
Summary String
