16
2. Installation
2.1 Name of Each Part
2.1.1 Slider Type (SA6/SA7)
2.1.2 Rod Type (RA54/RA64)
Connection port for teaching pendant or PC
(The arrow on the connector should face down.)
Non-motor end
Screw cover Coupling bolt
Right
Left
Motor end
Side cover LED
Top
Bottom
Front bracket
Slider
Rear bracket Motor bracket Rear cover
Base
Motor cover Cable
LED
Non-motor end Motor end
Right
Left
Coupling bolt
Front bracket
Rear bracket
Motor bracket Rear cover
Motor cover Cable
Connection port for teaching pendant or PC
(The arrow on the connector should face down.)
Rod Frame
Rod end bracket
Top
Bottom
